Home → Products → Vehicle Mounted industrial Computer
  Vehicle Mounted Industrial Computers
>> Atom E3845 (Bay Trail) Models >> Core i7 4650U (Haswell) Models
>> Atom E680T Models >> Atom N2800 Model
>> Atom D525 Models >> Atom Z520PT Models
>> Option
  Buchikiri Function
buchikiri Interface’s unique feature “Buchikiri”
Buchikiri is the function that safely turns off Windows PC without shutting down.
Interface computers with built-in “Buchikiri” function can be turned off by simply unplugging or turning off main power breaker. It will not cause any damage to the system or data.
  Intel Atom E3845 (Bay Trail) Models    Data Sheet Data Sheet
ETC-F019E ETC-F019(xx)E/ETC-F119(xx)E/ETC-F219(xx)E
The Vehicle Mounted Industrial Computer Atom E3845 (Bay Trail) model features high-performance processing with its quad-core 1.91 GHz CPU. It runs over wide temperature range from -30 degrees C to +80 degrees C at starting, or from -30 degrees C to +70 degrees C for continuous operation. CAN interface is included for vehicle mounted applications.

  Intel Core i7 4650U (Haswell) Models    Data Sheet Data Sheet
ETC-F019E SEC-E017(xx)E/SEC-E217(xx)E
The Vehicle Mounted Industrial Computer Core i7 (Haswell) model, combining dual core and Hyper Thread Technology, can operate simultaneously four threads in parallel. This feature enables fast data processing and expands hybrid OS applications. Turbo Boost Technology maximizes processor's capability by adjusting the operating frequency depending on the temperatures and processing loads.

  Intel Atom E680T Models    Data Sheet Data Sheet
ETC-D016E ETC-D016(xx)E/ETC-D116(xx)E/ETC-D216(xx)E
The Vehicle Mounted Industrial PC Atom E680T model achieves low power consumption and continuous 24/7 operation. Excellent thermal design enables it to operate in the wide temperature range from -30 degrees C to +80 degrees C at starting or from -30 degrees C to +70 degrees C for continuous operation. It features robust, small, silent, and anti-vibration protection that are perfect for embedded devices.

  Intel Atom N2800 Models    Data Sheet Data Sheet
SEC-D019E SEC-D019(xx)E/SEC-D119(xx)E/SEC-D219(xx)E
The Vehicle Mounted Industrial Computer Atom N2800 model features energy-efficient high-performance processing with its dual core CPU. It boasts rich interfaces using the Intel NM10 PCH chipset. CAN interface is included for vehicle mounted applications.

  Intel Atom D525 Models    Data Sheet Data Sheet
STC-B318E STC-B318(xx)E/STC-B418(xx)E/STC-B518(xx)E
The Vehicle Mounted Industrial Computer Atom D525 model features energy efficient and high-speed processing with its dual core processor. I/O interface is customizable and can be selected from various PCI Express boards for your application. The categories of the board include digital I/O, analog I/O, GP-IB, counter, motion, frame grabber, and so on.

  Intel Atom Z520PT Models
ETC-A013E ETC-A013(xx)E/ETC-A113(xx)E/
ETC-A213(xx)E
Data Sheet Data Sheet
The Vehicle Mounted Industrial Computer Atom Z520 PT model achieves low power consumption and continuous 24/7 operation. Excellent thermal design enables it to operate in the wide temperature range from -30 degrees C to +80 degrees C at starting or from -30 degrees C to +70 degrees C for continuous operation. It features robust, small, silent, and anti-vibration protection that are perfect for embedded devices.
ETC-A913E ETC-A913(xx)E/ETC-H913(xx)E
Front Access Model
Data Sheet Data Sheet
The Vehicle Mounted Industrial Computer Atom Z520 Front Access Model is single sided interface model, suitable for Transportation Vehicles & Industrial Automation Monitoring. It is empowered by the Intel Atom processor Z520PT industrial temperature options; it supports wide range temperature -30°C to +70°C for continuous operations. It can also operate with DC power input from +7 Vdc to +27 Vdc (or from +12 Vdc to +37 Vdc) for continuous operation.
  Optional Product
JPS-BUETC JPS-BUETC Battery Module for Vehicle Mounted Series
Automatic Reboot at Instantaneous Power Interruption

Automatic Reboot at Instantaneous Power Interruption
With the optional battery module (part no. JPS-BUETC), the system will shut down automatically when a sudden power failure occurs. The automatic shutdown process protects the system. The system can be programmed to reboot automatically after the power is restored. Perfect for unattended embedded systems.
*(xx):Selectable OS. Please see the data sheet for more details.
